ReadMe.md

VCAN-4-2-Industrial Demo (CAN-ETH-GW)

11.03.2024
VSpy 3.9.14.15

Showcase

Using CoreMini script on two VCAN4-2-Industrial.

First converts CAN1/2 input to ETH stream,\
Second receives the stream and converts back to CAN\

CAN1/CAN2, StdCAN/XtdCAN and StdCAN_FD/XtdCAN_FD will be transmitted each on an different ethernet port, but using same IP adresses.
Be aware, this example is not AUTOSAR conform.

Requirements

ISO15765_TX.vs3 and ISO15765_RX.vs3

Example setup to send and receive a ISO15765 multiframe message.
Setups could be used to send example Data to VCAN4-2_Industrial and receive on the second one.
