ReadMe.md

CMP Demo

Find Repository

Picture of Demosetup

General showcase

Demonstration of Intrepid device (neoVI-Fire3, neoVI-Red2)sending out data via ASAM CMP protocol.

Requirements

Used devices, cabeling ... Maybe adding links to devices (WEB) and files (Internal)
e.g.

[Remote datalogger](https://intrepidcs.com/products/data-loggers/) (neoVI-RED2/Fire3/Connect)

Remote datalogger (e.g. neoVI-RED2/Fire3/Connect)\

Setup I

Upload [Setup file](OBD_and_GPS_Collection.vs3zip)

Picture of Demosetup Upload Setup file

Showcase

  • neoOBDsim connected to Fire3/RED2
  • Fire3/Red2 receive CAN data
  • Fire3/red2 transmit CMP on ETH1
  • Additional SW/HW receiving CMP stream - DEWEsoft<\b>, Vigem Logger, WireShark

Setup II

If multiple setups are available

Showcase

Individual description of setup
